IMAGE SENSOR
Type
1/1.7 type back-illuminated CMOS
Effective Pixels
Approx. 12.1M
Colour Filter Type
Primary Colour
IMAGE PROCESSOR
Type
DIGIC 6 with iSAPS technology
LENS
Focal Length
5.2 - 26.0 mm (35 mm equivalent: 24 - 120 mm)
Zoom
Optical 5x
ZoomPlus 10x
Digital Approx. 4x (with Digital Tele-Converter Approx. 1.5x or
2.0x and Safety Zoom¹). Combined Approx. 20x
Maximum f/number
f/1.8-f/5.7
Construction
7 elements in 6 groups (1 double-sided aspherical lens, 1 double-sided aspherical UA lens and 1 single-sided aspherical lens)
Image Stabilisation
Yes (lens shift-type), approx. 3-stop¹. Intelligent IS with 5-axis Enhanced Dynamic IS
FOCUSING
Type
TTL
AF System/ Points
AiAF (9-point, Face Detection or Touch AF with Object and Face Select and Track), 1-point AF (any position is available or fixed centre)
AF Modes
Single, Continuous, Servo AF/AE¹, Touch AF
AF Point Selection
Size (Normal, Small)
AF Lock
On/Off Selectable
AF Assist Beam
Yes
Manual Focus
Yes, plus MF Peaking
Focus Bracketing
Yes
Closest Focusing Distance
3 cm (W) from front of lens in macro
EXPOSURE CONTROL
Metering modes
Evaluative (linked to Face Detection AF frame), Centre-weighted average, Spot (centre or linked to Face Detection AF or Touch AF frame)
AE Lock
Yes
Exposure Compensation
+/- 3 EV in 1/3 stop increments
Manual and automatic dynamic range correction
Automatic shadow correction
ND Filter (3 stop)
AEB
1/3 - 2 EV in 1/3 stop increments
ISO sensitivity*
AUTO, 80, 100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500, 3200, 4000, 5000, 6400, 8000, 10000, 12800
SHUTTER
Speed
1 - 1/2500 sec. (factory default)
250 - 1/2500 sec. (total range - varies by shooting mode)
WHITE BALANCE
Type
TTL
Settings
Auto (including Face Detection WB), Daylight, Cloudy, Tungsten,
Fluorescent, Fluorescent H, Flash, Underwater, Custom 1, Custom
2
Multi-area WB correction available in Smart Auto
White Balance Compensation
White Balance Compensation in Underwater mode
COLOUR MATRIX
Type
sRGB
VIEWFINDER
LCD MONITOR
Monitor
7.5 cm (3.0") PureColor II G Touch screen LCD (TFT). Approx. 922,000 dots. Capacitive type
Coverage
Approx. 100%
Brightness
Adjustable to one of five levels. Quick-bright LCD
FLASH
Modes
Auto, Manual Flash On / Off, Slow Synchro
Slow Sync Speed
Yes. Fastest speed 1/2000 sec.
Red-Eye Reduction
Yes
Flash Exposure Compensation
+/- 2 EV in 1/3 stop increments. Face Detection FE, Safety FE, Smart Flash Exposure
Flash Exposure Lock
Yes
Manual Power Adjustment
3 levels with internal flash
Second Curtain Synchronisation
Yes
Built-in Flash Range
50 cm - 7.0 m (W) / 50 cm - 2.3 m (T)
External Flash
Canon High Power Flash HF-DC2
SHOOTING
Modes
Smart Auto (58 scenes detected), Hybrid Auto, Program AE, Shutter priority AE, Aperture priority AE, Manual, Custom, SCN (Portrait, Smart Shutter (Smile, Wink Self-Timer, FaceSelf-Timer), Star (Star Nightscape, Star Trails, Star Time-Lapse Movie), Handheld Night Scene, Underwater, Snow, Fireworks), Creative Filters (High Dynamic Range, Nostalgic, Fish-eye Effect, Miniature Effect, Toy Camera Effect, Background Defocus, Soft Focus, Monochrome, Super Vivid, Poster Effect), Movie
Modes in Movie
Smart Auto (21 scenes detected), Standard, Program AE, Portrait, Nostalgic, Miniature Effect, Monochrome, Super Vivid, Poster Effect, Underwater, Snow, Fireworks, Super Slow Motion Movie
Photo Effects
My Colors (My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red, Custom Color)
Drive modes
Single, Auto Drive, Continuous, Continuous with AF, Self-Timer
Continuous Shooting
Approx. 12.1 shots/sec for up to 5 frames then approx. 9.4
shots/sec for 635 frames¹
with AF: Approx. 5.5 shots/sec²³
with Live View: Approx. 5.6 shots/sec²³
RECORDING PIXELS / COMPRESSION
Image Size
4:3 - (RAW, L) 4000 x 3000, (M1) 2816 x 2112, (M2) 1600 x 1200, (S)
640 x 480
16:9 - (RAW, L) 4000 x 2248, (M1) 2816 x 1584, (M2) 1920 x 1080,
(S) 640 x 360
3:2 - (RAW, L) 4000 x 2664, (M1) 2816 x 1880, (M2) 1600 x 1064, (S)
640 x 424
1:1 - (RAW, L) 2992 x 2992, (M1) 2112 x 2112, (M2) 1200 x 1200, (S)
480 x 480
4:5 - (RAW, L) 2400 x 3000, (M1) 1696 x 2112, (M2) 960 x 1200, (S)
384 x 480
Resize in playback (M2, S)
Compression
RAW, Superfine, Fine
Movies
(Full HD) 1920 x 1080, 60fps/30fps (HD) 1280 x 720, 30fps, (L) 640
x 480, 30fps
Star Time-Lapse Movie (Full HD) 15fps
Super Slow Motion Movie (L) 640 x 480, 120fps, (M) 320 x 240,
240fps
Miniature Effect (HD, L) 6fps, 3fps, 1.5fps
Hybrid Auto (HD)
Movie Length
(Full HD & HD) Up to 4 GB or 29 min. 59 sec.¹
(L and M) Up to 4 GB or 1 hour²
(Super Slow Motion Movie) 30 sec.
(Star Time-Lapse Movie) 8/6/4 sec
FILE TYPES
Still Image Type
JPEG compression (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system and DPOF ver. 1.1 compliant), RAW, RAW+JPEG
Movies
MP4 [Video: MPEG4-AVC (H.264), Audio: MPEG2 AAC-LC (stereo)]
DIRECT PRINT
Canon Printers
Canon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge
PictBridge
Yes (via USB or Wireless LAN)
OTHER FEATURES
GPS
GPS via mobile (linked to compatible smartphone)
Red-Eye Correction
Yes, during shooting and playback
My Category
Image tagging feature
Intelligent Orientation Sensor
Yes
Histogram
Yes, live histogram
Playback zoom
Approx. 2x - 10x
Self Timer
Approx. 2 or 10 sec., Custom
Menu Languages
English, German, French, Dutch, Danish, Finnish, Italian, Greek, Norwegian, Portuguese, Russian, Swedish, Spanish, Ukrainian, Polish, Czech, Hungarian, Turkish, Simplified Chinese, Chinese (traditional), Japanese, Korean, Thai, Arabic, Romanian, Farsi, Hindi, Malay, Indonesian, Vietnamese
INTERFACE
Computer
Hi-Speed USB (MTP, PTP) dedicated connector (Mini-B compatible)
Other
HDMI Mini Connector (HDMI-CEC compatible) A/V output (PAL/NTSC)
Computer/Other
Wireless LAN (IEEE802.11 b/g/n), (2.4 GHz only)¹
MEMORY CARD
Type
SD, SDHC, SDXC (UHS Speed Class 1 compatible)
SUPPORTED OPERATING SYSTEM
PC & Macintosh
Windows 8/7 SP1/ Vista SP2/ XP SP3
Mac OS X v10.6 - 10.8
For Wireless LAN connection to a PC:
Windows 8/7 SP1
Mac OS X v10.6.8/10.7/10.8.2 or later
SOFTWARE
Browsing & Printing
ImageBrowser EX
Other
Map Utility
Image Manipulation
Digital Photo Professional for RAW development
POWER SOURCE
Batteries
Rechargeable Li-ion Battery NB-6LH (NB-6LH battery and charger supplied)
Battery life
Approx. 230 shots
Eco mode approx. 300 shots
Approx. 240 min. playback
A/C Power Supply
Optional, AC Adapter Kit ACK-DC40
ACCESSORIES
Cases / Straps
Soft Case DCC-1920
Travel Case DCC-2500
Waterproof / Weatherproof Case
Waterproof Case (40m) WP-DC51, Waterproof Case Weight WW-DC1
Flash
Canon High Power Flash HF-DC2
Power Supply & Battery Chargers
AC Adapter Kit ACK-DC40, Battery Charger CB-2LYE
Other
Canon HDMI Cable HTC-100, interface cable IFC-400PCU
PHYSICAL SPECIFICATIONS
Operating Environment
0 - 40 °C, 10 - 90% humidity
Dimensions (WxHxD)
100.2 x 59.0 x 29.0 mm
Weight
Approx. 217 g (including battery/batteries and memory card)
Disclaimer
All data is based on Canon standard testing methods (according to CIPA Standards) except where indicated.
Subject to change without notice.
Footnote
¹ Depending on the image size selected.
¹ Values at maximum optical focal length. Cameras whose focal length exceeds 350mm (35mm equivalent) are measured at 350mm.
¹ Some settings limit availability.
¹ Sustained continuous shooting function requires compatible
SDHC/SDXC UHS Speed Class 1 memory card, total number of frames
captured varies depending on shooting subject.
² Under conditions where the flash does not fire.
³ Depending on memory card speed / capacity / compression setting.
¹ The following Speed Class memory cards are required for maximum
record time: (HD) 1280 x 720 Speed Class 4 or above. (Full HD) 1920
x 1080 Speed Class 6 or above. (iFrame) 1280 x 720 Speed Class 6 or
above.
² Depending on memory card speed / capacity / compression setting.
¹ Wi-Fi use may be restricted in certain countries or regions. Wi-Fi support varies by device and region. For more information visit www.canon-europe.com/wirelesscompacts
