POWER
Guide No. (ISO100).meters
60 (200mm)
ZOOM
Zoom head
Yes
focal length coverage
20-200mm
Coverage with wide panel
14mm
Auto zoom for sensor size
Yes
FLASH MODES
Auto exposure control
E-TTLII/E-TTL/TTL
High speed sync (FP)
Yes
Manual / output settings
Yes - 1/1-1/128
Manual steps
1/3 step
Strobe / output settings
Yes - 1/4-1/128
Frequency
1-500Hz (199Hz using optical receiver function)
FLASH-RELATED FUNCTION
FE lock
Yes
Flash exposure compensation
Yes
Flash Exposure bracketing
Yes
Second-curtain flash sync
Yes
Modelling flash
Yes
Colour temperature info communication
Yes
WIRELESS FLASH
Transmitter
Yes
Transmission type
Optical / Radio
Transmitter Max range approx
Indoors: 0.7-15m / 30m
Outdoors: 0.7-10m / 30m
Receiver
Yes
No of groups
3 / 5¹
No of channels
4 / 15
Remote Shutter Release
Yes
FLASH HEAD MOVEMENT
Up
45, 60, 75 and 90 °
Down
7 °
Left
60, 75, 90, 120, 150 and 180 °
Right
60, 75, 90, 120, 150 and 180°
AF ASSIST
AF-assist beam
Yes
Number of AF points supported
1 - 65
AF-assist beam type
Infra-red
POWER SOURCE
Battery
4 x AA batteries
Minimum recycling time
Approx. 3.3 sec¹
External power supply
Yes - CP-E4 / CP-E4N
CONSTRUCTION
Dust and water resistance
Yes
Mounting foot material
Metal
MISC.
Custom function
15 (6 personal functions)
Flash settings from camera menus
Yes¹
External flash exposure sensor
Yes
PC terminal
Yes
Compatible Accessories
Compact Battery Pack CP-E4N / CP-E4<br>Speedlite Transmitter ST-E3-RT<br>EX Series Speedlite with Receiver function<br>Off-camera shoe cord OC-E3<br>Bounce Adapter SBA-E3<br>Color Filter SCF-E3OR1 <br>Color Filter SCF-E3OR2
Dedicated flash bracket
SB-E2
DIMENSIONS & WEIGHT
Size (W x H x D), mm
78.7 x 143.2 x 122.7¹
Weight (Excluding batteries), grams
435g
Footnote
¹ As default only flash in group C are triggered wireless, set C.Fn 5-1 to wirelessly trigger groups A & B
¹ Time taken to recharge flash after full discharge using Alkaline AA batteries and Quick flash mode
¹ With compatible cameras only
¹ Except for the dust and water prevention adapter
