OVERVIEW
Model Numbers
MB5150
MB5155
Summary
Productive All-In-One for high volume printing small offices
Functions
Print, Copy, Scan, Fax, Wi-Fi, Ethernet + Cloud Link
PRINTER SPECIFICATIONS
Print Speed (approx.)
24.0 ipm mono A4¹
15.5 ipm colour A4¹
First Page Out Time (approx.)
Mono: 6 sec (ready) / 10 sec (sleep)
Colour: 7 sec (ready) / 12 sec (sleep)
Print Technology
Inkjet, FINE print head
Maximum Print Resolution
600 x 1200 dpi
Print Margins (min.)
Top: 3mm, Bottom: 5mm, Left & Right: 3.4mm
2-Sided Printing
Automatic (A4, LTR plain paper)
SCANNER SPECIFICATIONS
Scanner Type
Flatbed, ADF
Scanner Technology
2x CIS colour scanner
Scanner Resolution (Optical)
Up to 1200 x 1200 dpi¹
2-sided Scanning
Available (single pass)
Scan Speed (ADF) Approx.
Duplex. 23 ipm Col¹
Duplex. 23 ipm B/W¹
Maximum Document Size
Flatbed: A4, LTR (216x297mm)
ADF: A4, LTR, LGL
Scanning Depth (Input / Output)
Colour: 48 bit / 24 bit
Greyscale: 16 bit / 8 bit
Scan Functions
Scan to email, Scan to network folder, Scan to Cloud, Scan to USB
COPIER SPECIFICATIONS
Copy Speed (approx.)
ADF colour: 11.5 ipm¹
ADF mono: 22.0 ipm¹
Multiple Copy
Up to 99 pages
Reduction / Enlargement
25-400%, Fit to Page
Copy quality settings
Standard, High
Copy functions
Frame Erase, Collate, 2-on-1, 4-on-1
FAX SPECIFICATIONS
Fax Type
Super G3 / Colour
Fax Resolution
Mono: up to 300 x 300dpi
Colour: 200 x 200 dpi
Fax Speed
Mono: approx. 3 sec. (33.6kbps)¹
Colour: approx. 1 min. (33.6kbps)¹
Fax Memory
Up to 250 pages
Coded Speed Dialling
Max. 100 locations
Group Dial
Max. 99 locations
INKS & YIELD
Ink Type
Dual Resistant High Density ink
4 ink tanks (Black, Cyan, Magenta, Yellow)
XL Inks
PGI-2500XL BK (2500 pages)¹
PGI-2500XL C (1755 pages)¹
PGI-2500XL M (1295 pages)¹
PGI-2500XL Y (1520 pages)¹
Colour ink tanks (CMY) average yield: 1500 pages¹
PAPER SUPPORT
Paper Types
Plain Paper
Envelopes (DL, COM10, C5, Monarch)
Canon High Resolution Paper (HR-101N)
Canon Matte (MP-101)
Canon Pro Luster (LU-101)
Canon Plus Semi-gloss (SG-201)
Canon Plus Glossy II (PP-201)
Canon Glossy Everyday Use (GP-501)
Maximum Paper Input
Cassette: 250 sheets of plain paper
Paper Sizes
Plain paper: A4, A5, B5, LTR, LGL
Photo paper: A4, LTR, 20x25cm, 13x18cm, 10x15cm
Custom sizes: Width 89-215.9 mm, Length 127-355.6 mm
Paper Weight
Plain paper: 64 - 105 g/m²
Canon photo paper up to 275 g/m²
CONNECTIVITY
Wired Connections
Hi-Speed USB 2.0
Ethernet 10/100Mbps (auto switchable)
USB flash memory port (A type)
Wireless Connections
Wi-Fi IEEE802.11 b/g/n¹
Wireless LAN Frequency Band: 2.4GHz
Access Point Mode
Please refer to the user manual for instructions on how to activate/deactivate the wireless LAN.
Applications Support
Canon PRINT Inkjet/SELPHY app
MAXIFY Cloud Link (from printer screen or smart device)
Canon Print Service plug-in (Android)
Mopria
Microsoft Mobile Print
Apple AirPrint
SOFTWARE
Supported Operating System
Chrome OS
Windows 10 / 8.1 / 8 / 7 / 7 SP1 / Vista SP2
Windows Server 2008 / 2008 R2 / 2012 / 2012 R2
Mac OS X v10.8.5 or later
Supported Mobile Systems
iOS, Android, Windows RT, Windows 10 Mobile
Minimum System Requirements
Windows: Internet Explorer 8, internet connection or CD-ROM
Mac: Safari 5 and internet connection
Display: 1024x768 or higher
Software Included
Printer driver and fax driver
Quick Utility Toolbox
IJ Network Device Setup Utility
Easy-WebPrint EX
GENERAL FEATURES
Display Type & Size
8.8cm colour touch screen
Automatic Document Feeder
Up to 50-sheets
Dimensions (W x D x H)
463 x 394 x 291 mm
463 x 459 x 291 mm (paper installed)
Weight
11.4kg
Power Source
AC 100-240V, 50/60Hz
Power Consumption
Standby (scanning lamp is off)
USB connection to PC : approx. 0.9 Ｗ
Standby (all ports connected, scanning lamp is off) : approx. 1.7 W
Time to enter Standby mode : approx. 7 mins
OFF : approx. 0.2 W
Copying (USB connection to PC): approx. 25 W¹
Typical Electricity Consumption
0.16 kWh¹
Noise Levels
Approx. 56 dB(A)¹
Recommended Operating Environment
Temperature: 15-30°C
Humidity: 10-80%RH (no dew condensation)
Duty Cycle (monthly)
up to 30,000 pages¹
Recommended Print Volume
250-1500 pages / month
Disclaimer
All specifications subject to change without notice.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
Copy speed may vary depending on document complexity, copy mode, page coverage; type of paper used etc. and does not take into account warming up time.
Actual fax transmission speed may vary depending on document complexity, fax settings at receiving end, and line conditions etc.
Ink yield may vary depending on documents printed, applications software used, print mode and type of paper used. For more information see www.canon-europe.com/ink/yield
All brand and product names are trademarks of their respective companies.
Footnote
¹ Document print speed on plain paper is measured based on average of ESAT in Office Category Test of ISO/IEC 24734 standard.
¹ Optical resolution is a measure of maximum hardware sampling resolution based on ISO 14473 standard. When scanning in high resolution, the scan size is restricted.
¹ ADF scan speeds are the average of scESAT30secA in "ADF Productivitiy Measurement" test, ISO/IEC 17991:2015. When scanning or copying a certain volume of documents (approx. 150 sheets in default settings) continuously from the ADF, the printer may switch to “waiting mode“ in which paper feeding stops for several tens of seconds after each scan to prohibit overheating the ADF.
¹ ADF copy speed is the average of ESAT simplex, ISO/IEC 24735, excluding time to copy the first set. When scanning or copying a certain volume of pages continuously using the ADF, the printer may need to do a pause (usually less than 1 minute) after each scan. This is to prevent the paper feeding mechanism overheating. When scanning or copying in default settings (colour, 300dpi), the page feeding starts to pause after approx. 80 sheets of paper when fed continuously or repeatedly in a short period of time. The pause time may vary depending on scan settings including colour or mono and scan resolution.
¹ Based on default setting using ITU-T No.1 chart for mono and Canon Colour Fax Test Sheet for colour.
¹ Page yield is based on ISO/IEC 24711 and continuous printing. Printer ships with setup ink tanks.
¹ Wi-Fi frequency band: 2.4GHz, Wi-Fi Security: WPA-PSK, WPA2-PSK, WEP, Administration password
¹ Copy: When copying ISO/JIS-SCID N2 (printed by inkjet printer) on A4 size plain paper using default settings. Specifications are subject to change without notice.
¹ Typical Energy Consumption (TEC) represents the typical electricity consumed by a product during one week.
¹ Acoustic Noise is measured based on ISO7779 standard.
¹ Duty cycle is defined as a maximum number of printed pages for a single peak month.
