Canon PIXMA PRO-1 Specifications
PRINT SPECIFICATIONS
Print Resolution
Up to 4800¹ x 2400 dpi
Print Engine
Inkjet 12 Single Inks System
LUCIA inks with Chroma Optimizer
FINE print head with 4pl droplet size
Photo Lab Quality Speed
A3+ (SG-201 or PP-201): Approx. 2min 55s¹
A3+ (PT-101 colour or mono): Approx. 4min 20s¹
Borderless Printing
Yes (A3+, A3, A4, Letter, 36 x 43cm, 25 x 30cm, 20 x 25cm, 13 x 18cm, & 10 x 15cm sizes¹
Direct Disc Printing
Available as standard
Two Sided Printing
Available by manual operation only
Driver Features
Black and White Print, Vivid Photo, Manual Colour Adjustment, Clear Coating settings, Photo Noise Reduction, Monochrome Effects, Collate, Multiple page per sheet print, Booklet print, Poster print, Scaled print (20-400%), Fit-to-Page print, Quiet Mode, Auto Power Off settings¹
INK AND PAGE YIELD
Ink Cartridge Configuration
12 separate ink tanks:
PGI-29PBK (Photo Black)
PGI-29MBK (Matte Black)
PGI-29DGY (Dark Grey)
PGI-29GY (Grey)
PGI-29LGY (Light Grey)
PGI-29C (Cyan)
PGI-29PC (Photo Cyan)
PGI-29M (Magenta)
PGI-29PM (Photo Magenta)
PGI-29Y (Yellow)
PGI-29R (Red)
PGI-29CO (Chroma Optimizer)
Ink Tanks Life - 10x15cm Photo Printing
Number of 10x15cm photos¹
Photo Black: 1225 photos*
Matte Black: 1345 photos*
Dark Grey: 670 photos
Grey: 790 photos
Light Grey: 1320 photos
Cyan: 1800 photos*
Photo Cyan: 1375 photos
Magenta: 1755 photos*
Photo Magenta: 1055 photos
Yellow: 1280 photos
Red: 2460 photos*
Chroma Optimiser: 429 photos
* Estimated Supplemental Yield
Ink Tanks Life - A3+ Photo Printing
Number of A3+ colour photos¹
Photo Black: 111 photos
Matte Black: 505 photos*
Dark Grey: 119 photos
Grey: 179 photos
Light Grey: 352 photos*
Cyan: 230 photos
Photo Cyan: 400 photos*
Magenta: 281 photos
Photo Magenta: 228 photos
Yellow: 290 photos
Red: 454 photos*
Chroma Optimiser: 90 photos
* Estimated Supplemental Yield
PAPER SUPPORT
Paper Types
Plain Paper
Canon Pro Platinum (PT-101)
Canon Pro Luster (LU-101)
Canon Pro Premium Matt (PM-101)
Canon Plus Glossy II (PP-201)
Canon Plus Semi-gloss (SG-201)
Canon Matte (MP-101)
Canon Museum Etching (FA-ME1)
Canon Photo Stickers (PS-101)
Other Fine Art, Canvas and Glossy Photo Papers¹
Maximum Paper Input
Rear Tray: Max. 150 sheets
Manual Feeder: 1 sheet
Direct Disc Print Tray: 1 printable CD, DVD or Blu-Ray Disc
Paper Sizes
Rear Tray: A3+, A3, A4, A5, B4, B5, Letter, Legal, 25x30cm (10x12"), 20x25cm (8x10"), 13x18cm, 10x15cm
Manual Feeder: A3+, A3, A4, Letter, 36x43cm (14x17"), 25x30cm (10x12"), 20x25cm (8x10")
Paper Weight
Rear Tray: Plain paper (64 to 105 g/m²) and supported Canon special media up to approx. 300 g/m²
Manual Feeder: Canon special media up to approx. 350g/m² and 0.6mm
INTERFACE
Interface Type - PC / Mac
Ethernet: 10/100Mbps (auto switchable)
Hi-Speed USB 2.0 (B port)
Interface Type - Non PC
USB PictBridge
SOFTWARE
Software Included
Windows and Mac Driver
Print Studio Pro plug-in¹
Colour Management Tool Pro (download)
My Image Garden with Full HD Movie Print²
Easy-WebPrint EX (download)³
Quick Menu
Supported Operating System
Windows 10 (32 and 64bit)
Windows 8 (32 and 64bit)
Windows RT
Windows 7 (32 and 64bit)
Windows Vista (32 and 64bit)
Windows XP (32bit)
Mac OS X v10.4.11 or later
Windows System Requirements
Windows 7: 1GHz or faster CPU, 1GB RAM (32bit) / 2GB RAM (64bit)
Windows Vista (32 and 64 bit): 1GHz or faster CPU, 512MB RAM
Windows XP SP2, SP3: 300MHz or faster CPU, 128MB RAM
Browser: Internet Explorer 6 or higher
CD-ROM Drive
Display: 800 x 600 or better
Mac System Requirements
Mac OS X v10.6: Intel Processor, 1GB RAM
Mac OS X v10.5: Intel or PowerPC Processor (G4, G5, 867MHz or faster)
Mac OS X v10.4.11: Intel or PowerPC Processor (G5, G4, G3), 256MB RAM
Browser: Safari 3 or higher
CD-ROM Drive
Display: XGA 1024 x 768 or better
PHYSICAL FEATURES
Power Source
AC 100-240V, 50 / 60Hz
Power Consumption
Off: Approx. 0.4 W
Standby (connected to PC via USB): Approx. 1.6 W
Standby (all ports connected): Approx. 1.8 W
Time to enter Standby mode: 2 minutes
Printing: Approx. 24W¹
Temperature Range
Operating environment: 5° - 35° C
Humidity
Operating humidity: 10 - 90%RH (no condensation)
Acoustic Noise Levels
Approx. 35.5 dB(A)¹
Dimensions (W x D x H)
695 x 462 x 239 mm
Weight
Approx. 27.7 kg
Disclaimer
All specifications subject to change without notice.
Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
Ink yield may vary depending on texts/photos printed, applications software used, print mode and type of paper used. For yield information see www.canon-europe.com/ink/yield
All brand and product names are trademarks of their respective companies.
Microsoft, Windows and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Footnote
¹ Ink droplets can be placed with a minimum pitch of 1/4800 inch.
¹ 11"X14" image printed with borders onto A3+ paper in default settings using ISO/JIS-SCID N2.
¹ When printing on Fine Art Papers top and bottom margins are minimum 30mm.
¹ Some features available in Windows driver only.
¹ Declared yield value in accordance with ISO/IEC 29102. Values obtained by continuous printing.
¹ When printing ISO/JIS-SCID N2 pattern at 11"x14" size continuously on A3+ photo paper Pro Platinum (PT-101), with the default settings using Windows 7 printer driver and Photoshop CS4.
¹ Support for a range of non-Canon papers. ICC profiles and Art Paper Printing Guide instructions manual can be downloaded from http://software.canon-europe.com/
¹ Print Studio Pro is a printing software plug-in for the Canon Digital Photo Professional (3.12 or later), Adobe Photoshop (CS4 or later), Adobe Photoshop Elements (8 or later), Adobe Photoshop Lightroom (2.7 or later).
² Full HD Movie Print is available for MOV and MP4 movie files created by Canon digital and video cameras. Requires installation of software bundled with Canon video or digital camera, from which the movie was captured. MOV files require: ZoomBrowser EX / ImageBrowser (version 6.5 or later), MP4 files require: ImageBrowser EX (version 1.0 or later).
³ Easy-WebPrint EX requires Internet Explorer 7 or later.
¹ When printing ISO/JIS-SCID N2 pattern on A4 size plain paper using default settings.
¹ When printing ISO/JIS-SCID N2 pattern on 10x15cm Photo Paper Plus Glossy II using default settings.
