GENERAL PRODUCT INFORMATION
Type
Universal A3 Flatbed Scanner Option
Scanning sensor unit
CCD Sensor
Optical resolution
600dpi
Light source
LED RGB
Scanning side
Front
Interface
High speed USB 2.0
Dimensions (WxDxH)
Tray Closed: 571mm (W) x 436 (D) x 96 (H) mm
Weight
Approx. 8.5Kg
Power requirements
AC100 - 240V (50/60Hz)
Power consumption
Scanning 21W or less, Sleep Mode 3.1W or less, Power Turned Off less that 0.3W
Operating environment
10 - 32.5°C (50 - 90.5°F), Humidity: 20 - 80% RH
Environmental compliance
RoHS and ENERGY STAR
SCANNING SPEED (200DPI)
Black and White
A4: 3.0 seconds A3: 3.5 seconds
Colour
A4: 3.5 seconds A3: 4.5 seconds
Output resolution
100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi
Output mode
Black and White, Error Diffusion, Advanced Text Enhancement II, 8-bit Greyscale (256-level), 24-bit Colour, Auto Colour Detection
DOCUMENT SPECIFICATIONS
Width
Up to 297.4mm
Length
Up to 431.8mm
SPECIAL FEATURES
-
Automatic Page Size Detection, Deskew, Ambient Light Cancelling Mode, Scan Area Setting, Scanning side, Contrast Arrangment Automatic Resolution Setting.
(Inherits image processing function from connected DR-series scanners)
Disclaimer
All data is based on Canon standard testing methods except where indicated.
Subject to change without notice.
