OPTICAL FEATURES/SPECIFICATIONS
Angle of view (horzntl, vertl, diagnl)
98° - 54°,
74°10′ - 38°,
108°10′ - 63°
Lens construction (elements/groups)
16/12
No. of diaphragm blades
9
Minimum aperture
22
Closest focussing distance (m)
0.28
Maximum magnification (x)
0.23x (at 35mm)
Distance Information
Yes
Image stabilizer*
4.0
AF actuator
Ring USM¹
PHYSICAL SPECIFICATIONS
Dust/moisture resistance**
Yes
Filter diameter (mm)
77
Max. diameter x length (mm)
82.6 x 112.8
Weight (g)
615
ACCESSORIES
Lens cap
E-77 II
Lens hood
EW-82
Lens case/pouch
LP1219
Rear cap
Lens Dust Cap E
Magnification w/ Extension Tube EF12 II
0.63-0.36¹
Magnification w/ Extension Tube EF25 II
1.12-0.80¹
Extender Compatiblity
Not Compatible
Other Accessories
Close-up lens 500D, tele only - 0.07 to 0.28x
Gelatin Filter Holder IV for full telephoto only
SPECIFICATIONS WITH EF 1.4X II
SPECIFICATIONS WITH EF 2X II
Disclaimer
* Tested under CIPA standards
** Lenses with dust/moisture resistance are fitted with a rubber ring on the lens mount which may cause sligth abrasion of the camera mount.
This in no way effects either the lens or camera performance.
* Tested under CIPA standards
** Lenses with dust/moisture resistance are fitted with a rubber ring on the lens mount which may cause sligth abrasion of the camera mount.
This in no way effects either the lens or camera performance.
Footnote
¹ Full time Manual focus
¹ Not Compatible at wide angles
¹ Not Compatible at wide angles
¹ Full time Manual focus
¹ Not Compatible at wide angles
¹ Not Compatible at wide angles
